| BE-438FXII | |||||
|---|---|---|---|---|---|
| Application | Button attaching | ||||
| Lubrication | Semi-dry | ||||
| Max. sewing speed | 2,700sti/min | ||||
| Max. sewing area | Max.6.4×6.4mm | ||||
| Dimensions of buttons that can be sewn | Outer diameter of buttons 8-30mm*1 | ||||
| Stitch length | 0.05～6.4mm | ||||
| Feed mechanism | Y-θintermittent feed mechanism (pulse-motor driven mechanism) | ||||
| No. of stitches | Variable (Refer to “Program List” for details on the number of stitches for sewing patterns that are already preset) | ||||
| Max.No. of stitches | 5,000 stitches/pattern | ||||
| Work clamp lifter | Pulse motor drive system | ||||
| Work clamp height / Button clamp height | Max. 13mm | ||||
| Rotary hook | Shuttle hook (double shuttle hook, optional) | ||||
| Digital tension | Standard equipment | ||||
| Thread wiper | Standard equipment | ||||
| Thread trimmer | Standard equipment | ||||
| Thread nipper | Standard equipment | ||||
| Data storage method | Flash memory (Any sewing pattern can be added using SD card) | ||||
| Exteernal data storage method | SD card*2 | ||||
| No. of cycle programs | 30 cycle (50 programs for each cycle) | ||||
| No. of stored data | 64 sewing patterns are set already | ||||
| (up to 512 patterns can be added. Total number of stitches of stored data which can be added is within 500,000*3) | |||||
| Motor | AC servo motor 550W (Direct Drive) | ||||
| Weight | Machine head: Approx. 57kg, Operation panel: Approx. 0.4kg, Control box: Approx. 9kg | ||||
| Power supply | Single-phase 100V/200V, 3 phase 220V/380V/400V 400VA (For single-phase 100V and 3-phase 380V/400V, the trans box is require | ||||
