NEXIO BAS-360H

・Bridge type mechanism provides great sewing quality at higher sewing speeds
・World’s top-class productivity and sewing quality with Great sewing speeds（Max. 2,700sti/min)
・User-friendly Color LCD with Touch Panel Display
・A needle cooler preventing thread breakage thus for greater sewing speeds
・For Use with Various Types of Sewing Applications
・Max. sewing area: 500mmx400mm

Southeast Technocrafts Ltd.

Hurry and get discounts on all Apple devices up to 20%

Call for price

Compare

Add to wishlist

Description

	BAS-360H
Stitch form	Single needle lock stitch
Max. sewing speed	2,700sti/min (R spec: 2,200sti/min)
Max. sewing area	500x400mm
Footprint	1,489mmx1,296mm
Feed mechanism	Intermittent feed (pulse motor drive)
Stitch length	0.05-20.0mm (per 0.05mm)
Max. number of stitches	100,000 stitches (per program)
Max. number of programs	999
Work clamp lift amount	Max. 52.5mm
Height of stepping presser foot	25mm(highest needle stop position)
Stepping presser foot stroke	0-10mm(per 0.1 mm)
Work clamp	Pneumatic work clamp
Head lifting function	–
Head lifetable	–
Needle cooler	Standard equipment
Thread wiper	Standard equipment
Thread trimmer	Standard equipment
Digital tension	Standard equipment
Thread breakage detector	Standard equipment (fiber sensor drive)
Data storage media	Internal flash memory (data addition is availabe with external memory)
Motor	AC servo motor 550W
Weight	Approx. 630kg
Power	Single phase 220V / 230V 3-phase 200V / 220V / 380V / 400V
Apparent power/Power consumption	950VA/ 560Wh
Air pressure/Consumption	0.5MPa/Needle cooler ON:8l/min OFF:0.2/min
