Specifications
| S-7780A | |||||
|---|---|---|---|---|---|
| Lubrication | Minimum lubrication | ||||
| Application | Medium materials | ||||
| Max. sewing speed | 4,500sti/min | ||||
| Max. stitch length | 4mm | ||||
| Feed system | Direct electronic feed control | ||||
| Presser foot height | Presser bar lifter: 5mm, Knee lifter: 13mm | ||||
| Needle bar stroke | 31mm | ||||
| Needle（DBx1） | #11-#18(Nm75-110) | ||||
| Standard cutting width | 3.2mm (1/8) or 6.4mm (1/4) | ||||
| Max. thickness of the material to be cut | 4mm | ||||
| Quick back device | Standard equipment | ||||
| Thread presser | Standard equipment | ||||
| Weight | 37kg | ||||
| Power | Single phase: 110V* /Single phase, 3-phase: 200V-230 V Max. electric power consumption 550VA * The transformer is required. |
||||
