| Model | Z-8550A |
|---|---|
| Direct drive | ◯ |
| Max. zigzag width | 10.0mm*1 |
| Application | Light materials Medium materials |
| Presser foot height | Manual : 6.0mm Knee : 10.0mm |
| Needle bar stroke | 33.3mm |
| Max. sewing speed | 5,000sti/min*2 |
| Max. feed amount | 5.0mm*3 |
| Sewing pattern | 8 types, 14 patterns built-in (Custom patterns can be added up to 99 patterns with a total of 49,500 stitches, 500 stitches or less per pattern.) |
| Thread take-up | Rotary |
| Height of feed dog | 1.0mm |
| Presser foot pressure | 10-30N |
| Needle | Schmetz 134SUKNm70/10 |
| Weight | Machine head : 44.4kg Control box : 14-15kg |
| Arm pocket size | Arm pocket width : 300.0mm Arm pocket height : 121.5mm |
| Arm bed size | 517.5×178.0mm |
| Motor | AC servo motor (4-pole,550W) |
| Power | Single-phase: 100V 3-phase: 200V Max. electric power consumption: 400VA |
| Control circuit | Microprocessor |
